Haiyang
Haiyang HD-70CF
The Haiyang HD-70CF is a 7-inch Windows-based fishfinder/GPS combo with a wide color LCD, multi-constellation GNSS positioning, and IMO Resolution MSC.112(73) compliance for commercial marine use.
- Brand
- Haiyang
- Category
- Marine
- Availability
- Enquire for lead time
Technical
Specifications
| Operating System | Microsoft Windows |
|---|---|
| Display Screen | 7 inch wide color LCD with LED backlight |
| Power Supply | DC 12V ~ 36V (±10%), 12W |
| Operation Temperature (Display Unit) | -15°C ~ +50°C |
| Operation Temperature (Antenna Unit) | -25°C ~ +70°C |
| Performance Standard | IMO Resolution MSC.112(73) |
| Back-up | SD Card (Optional) |
| Option | HAIYANG Chart with SD Card |
| GNSS Receiver Capabilities | GPS L1 C/A code, GLONASS L10F, QZSS L1 C/A code, Galileo E1B/E1C/L1 |
| Number of Channel | 52 channel over |
| Horizontal Positioning Accuracy (Autonomous) | 2.5m (CEP 50%) |
| Sensitivity | Acquisition -148 dBm, Tracking -165 dBm, Reacquisition -162 dBm |
| Nav Update | 1Hz |
| Support | DGPS, SBAS (EGNOS, WAAS, MASA, GAGAN, GLONASS) |
| Display Method | Mercator projection |
| Display Mode | True motion/N/S/E/W up/Course up/Head up |
| Latitude Limits | Between 85°N to 85°S |
| Map Scale | 0.05NM to 1,500NM |
| Map Datum | WGS-84 |
| Waypoint | 100,000 points (16 colors and 16 icons selectable per point) |
| Track Point | 50,000 points (2 types) |
| Route | Max capacity 100 Routes (20 WPTs per Route, each with name tags of 8 alphanumeric characters) |
| Draw Point | 1,000 points |
| Area Name | 1,000 points |
| Chart Data | HY-MAP (Built-in or External)/C-MAP/Navionics |
| Output Data | NMEA-0183 |
| Input Data | NMEA-0183 |
| Alarm | Arrival, Anchor, XTE, Interval timer, Userline |
Overview
About this product
The Haiyang HD-70CF pairs a 7 inch wide color LCD running on a Microsoft Windows platform with a GNSS receiver covering GPS, GLONASS, QZSS, and Galileo signals across 52-plus channels, backed by DGPS and SBAS augmentation for improved positioning accuracy. It stores up to 100,000 waypoints, 50,000 track points, and 100 routes, supports HY-MAP, C-MAP, and Navionics chart data, and offers optional SD card backup along with HAIYANG chart cards. Built to IMO Resolution MSC.112(73) and powered from a DC 12V to 36V supply, the antenna unit is rated for operation from -25°C to +70°C.
Questions
Frequently asked questions
What operating system does the HD-70CF run?
It runs on Microsoft Windows.
What size is the HD-70CF display?
It has a 7-inch wide color LCD with LED backlight.
What satellite systems does the HD-70CF's GPS receiver support?
The HD-70CF's GNSS receiver tracks GPS L1 C/A code, GLONASS L1OF, QZSS L1 C/A code and Galileo E1B/E1C/L1 across more than 52 channels, with DGPS and SBAS (EGNOS, WAAS, MSAS, GAGAN, GLONASS) augmentation support.
How many waypoints and routes can the HD-70CF store?
It stores up to 100,000 waypoints, 50,000 track points, and a maximum of 100 routes with 20 waypoints per route.
