Haiyang
Haiyang HD-77F
The Haiyang HD-77F is a 7-inch Windows-based chartplotter with a wide color LED-backlit display, 20,000-waypoint capacity, and AIS-alarm support, compliant with IMO Resolution MSC.112(73).
- Brand
- Haiyang
- Category
- Marine
- Availability
- Enquire for lead time
Technical
Specifications
| Operating System | Microsoft Windows |
|---|---|
| Display Screen | 7 inch wide color LED backlight |
| Power Supply | DC 12V ~ 36V (±10%), 12W |
| Operation Temperature (Display Unit) | -15°C ~ +50°C |
| Operation Temperature (Antenna Unit) | -25°C ~ +70°C |
| Performance Standard | IMO Resolution MSC.112(73) |
| Back-up | SD Card (Optional) |
| Optional | HAIYANG Chart with SD Card |
| Display Method | Mercator projection |
| Display Mode | True motion/North up/Course up/Head up |
| Latitude Limits | Between 85°N to 85°S |
| Map Scale | 0.05NM to 1500NM |
| Map Datum | WGS-84 |
| Waypoint | 20,000 points |
| Track Point | 50,000 points |
| Route | 100 Routes |
| Draw Point | 1,000 points |
| Area Name | 1,000 points |
| Chart Data | Built-in/C-MAP/HY Chart (SD Card) |
| Output Data | NMEA-0183 |
| Input Data | NMEA-0183 |
| Alarm | Arrival, Anchor, Off course, Interval timer, AIS (CPA, TCPA) |
Overview
About this product
The Haiyang HD-77F runs on a Microsoft Windows platform with a 7 inch wide color LED-backlit display and a Mercator-projection chart display supporting true motion, north up, course up, and head up modes. It stores 20,000 waypoints, 50,000 track points, and 100 routes, reads built-in, C-MAP, or HAIYANG SD card chart data, and includes arrival, anchor, off-course, and AIS (CPA/TCPA) alarms. It meets IMO Resolution MSC.112(73), runs on a DC 12V to 36V supply, and offers optional SD card backup with HAIYANG chart cards.
Questions
Frequently asked questions
What screen size does the Haiyang HD-77F chartplotter have?
The HD-77F has a 7 inch wide color LED backlight display and runs on a Microsoft Windows operating system.
What is the power requirement for the Haiyang HD-77F?
The HD-77F runs on DC 12V to 36V (plus or minus 10%) and draws 12W.
How many waypoints and routes can the HD-77F store?
The HD-77F stores up to 20,000 waypoints, 50,000 track points and 100 routes, with 1,000 draw points and 1,000 area names.
What chart data does the Haiyang HD-77F support?
The HD-77F uses built-in charts or HAIYANG Chart via SD card, and also supports C-MAP. It meets IMO Resolution MSC.112(73) and outputs and inputs data over NMEA-0183.
