Icom
ID-RP4010V
A UHF D-STAR repeater for 440-450 MHz with 25 W high-power output and both DV digital voice and FM analog operation.
- Brand
- Icom
- Category
- Amateur Radio
- Manufacturer
- Icom website ↗
- Availability
- Enquire for lead time
Technical
Specifications
| Frequency range (USA, TX/RX) | 440–450 MHz |
|---|---|
| Type of emission | F3E, F7W, F2A (ID transmission) |
| Frequency stability | ±0.5 ppm or less (–10 °C to +50 °C) |
| Transfer rate | DV: 4.8 kbps |
| Antenna impedance | 50 Ω |
| Power supply | 13.8 V DC ±15% |
| Current drain TX | Less than 7.0 A (High), 3.0 A (Low) |
| Current drain RX | Less than 1.8 A |
| Operating temperature | –10 °C to +50 °C |
| Dimensions | 482 × 88 × 275 mm |
| Weight | 6 kg (13.2 lb) |
| Output power | 25 W (High), 2.5 W (Low) |
| DV modulation | Digital GMSK |
| FM modulation | Digital Reactance modulation |
| DV occupied bandwidth | Less than 6 kHz |
| Maximum frequency deviation (FM) | ±5.0 kHz/±2.5 kHz |
| Spurious emissions | Less than –61.8 dB |
| Receiver system | RF Direct Sampling |
| DV sensitivity | Less than –13 dBμV (0.22 μV) |
| FM sensitivity | Less than –15 dBμV (0.18 μV) |
| Audio output power | More than 2.0 W |
Overview
About this product
The ID-RP4010V is a D-STAR digital voice repeater covering 440-450 MHz, transmitting DV and FM signals with GMSK digital modulation and F2A ID transmission. Output power is 25 W on high and 2.5 W on low, with DV sensitivity rated below -13 dBμV (0.22 μV) and FM sensitivity below -15 dBμV (0.18 μV), drawing up to 7.0 A on transmit from a 13.8 V DC supply. It measures 482 x 88 x 275 mm, weighs 6 kg, and is rated to operate from -10°C to +50°C.
Questions
Frequently asked questions
What output power does the ID-RP4010V repeater deliver?
The ID-RP4010V delivers 25 W on High and 2.5 W on Low.
What frequency range does the ID-RP4010V cover?
The ID-RP4010V covers 440-450 MHz (USA version).
Does the ID-RP4010V support D-STAR digital voice?
Yes, it supports F3E (analog FM), F7W (digital) and F2A (ID transmission) emission modes, with a D-STAR digital voice transfer rate of 4.8 kbps.
How much does the ID-RP4010V weigh?
The ID-RP4010V weighs 6 kg (13.2 lb) and measures 482 x 88 x 275 mm.
