Haiyang
Haiyang HD-70C
The Haiyang HD-70C is a 7-inch Windows-based chartplotter with a wide color LCD, multi-constellation GNSS positioning, and IMO Resolution MSC.112(73) compliance for commercial marine use.
- Brand
- Haiyang
- Category
- Marine
- Availability
- Enquire for lead time
Technical
Specifications
| Operating System | Microsoft Windows |
|---|---|
| Display Screen | 7 inch wide color LCD with LED backlight |
| Power Supply | DC 12V ~ 36V (±10%), 12W |
| Operation Temperature (Display Unit) | -15°C ~ +50°C |
| Operation Temperature (Antenna Unit) | -25°C ~ +70°C |
| Performance Standard | IMO Resolution MSC.112(73) |
| Back-up | SD Card (Optional) |
| Option | HAIYANG Chart with SD Card |
| GNSS Receiver Capabilities | GPS L1 C/A code, GLONASS L10F, QZSS L1 C/A code, Galileo E1B/E1C/L1 |
| Number of Channel | 52 channel over |
| Horizontal Positioning Accuracy (Autonomous) | 2.5m (CEP 50%) |
| Sensitivity | Acquisition -148 dBm, Tracking -165 dBm, Reacquisition -162 dBm |
| Nav Update | 1Hz |
| Support | DGPS, SBAS (EGNOS, WAAS, MASA, GAGAN, GLONASS) |
| Display Method | Mercator projection |
| Display Mode | True motion/N/S/E/W up/Course up/Head up |
| Latitude Limits | Between 85°N to 85°S |
| Map Scale | 0.05NM to 1,500NM |
| Map Datum | WGS-84 |
| Waypoint | 100,000 points (16 colors and 16 icons selectable per point) |
| Track Point | 50,000 points (2 types) |
| Route | Max capacity 100 Routes (20 WPTs per Route, each with name tags of 8 alphanumeric characters) |
| Draw Point | 1,000 points |
| Area Name | 1,000 points |
| Chart Data | HY-MAP (Built-in or External)/C-MAP/Navionics |
| Output Data | NMEA-0183 |
| Input Data | NMEA-0183 |
| Alarm | Arrival, Anchor, XTE, Interval timer, Userline |
Overview
About this product
The Haiyang HD-70C runs a Microsoft Windows platform behind a 7 inch wide color LCD with LED backlight, driven by a 52-plus channel GNSS receiver covering GPS, GLONASS, QZSS, and Galileo signals with DGPS and SBAS augmentation. It stores up to 100,000 waypoints, 50,000 track points, and 100 routes, and reads HY-MAP, C-MAP, and Navionics chart data over a Mercator projection display. Built to IMO Resolution MSC.112(73), it runs on a DC 12V to 36V supply and offers optional SD card backup with HAIYANG chart cards.
Questions
Frequently asked questions
What display does the Haiyang HD-70C use?
The HD-70C has a 7 inch wide color LCD with LED backlight and runs on a Microsoft Windows operating system.
What chart formats are compatible with the HD-70C?
The HD-70C supports HY-MAP (built-in or external), C-MAP and Navionics chart data.
How many waypoints can the Haiyang HD-70C hold?
The HD-70C stores up to 100,000 waypoints (16 colors and 16 icons selectable per point), 50,000 track points, and up to 100 routes with 20 waypoints per route.
What GNSS accuracy does the HD-70C offer?
It offers 2.5m (CEP 50%) autonomous horizontal positioning accuracy, receiving GPS, GLONASS, QZSS and Galileo signals over 52-plus channels with DGPS/SBAS support.
