Haiyang HD-880C
The Haiyang HD-880C is an 8-inch SVGA chartplotter with multi-constellation GNSS positioning and IMO Resolution MSC.112(73) compliance for commercial marine use.
- Brand
- Haiyang
- Category
- Marine
- Availability
- Enquire for lead time
Technical
Specifications
| Display Screen | 8 inch color LCD with LED backlight |
|---|---|
| Resolution | SVGA (800 x 600 pixels) |
| Power Supply | DC 12V ~ 36V (±10%) |
| Operation Temperature (Display Unit) | -15°C ~ +50°C |
| Operation Temperature (Antenna Unit) | -25°C ~ +70°C |
| Performance Standard | IMO Resolution MSC.112(73) |
| GNSS Receiver Capabilities | GPS L1 C/A code, GLONASS L10F, QZSS L1 C/A code, Galileo E1B/E1C/L1 |
| Number of Channel | 52 channel over |
| Horizontal Positioning Accuracy (Autonomous) | 2.5m (CEP 50%) |
| Sensitivity | Acquisition -148 dBm, Tracking -165 dBm, Reacquisition -162 dBm |
| Nav Update | 1Hz |
| Support | DGPS, SBAS (EGNOS, WAAS, MASA, GAGAN, GLONASS) |
| Display Method | Mercator projection |
| Display Mode | True motion/N/S/E/W up/Course up/Head up |
| Latitude Limits | Between 85°N to 85°S |
| Map Scale | 0.05NM to 1,500NM |
| Map Datum | WGS-84 |
| Waypoint | 100,000 points (16 colors and 16 icons selectable per point) |
| Track Point | 50,000 points (2 types) |
| Route | Max capacity 100 Routes (20 WPTs per Route, each with name tags of 8 alphanumeric characters) |
| Draw Point | 1,000 points |
| Area Name | 1,000 points |
| Chart Data | HY-MAP (Built-in or External)/C-MAP 4D |
| Output Data | NMEA-0183 |
| Input Data | NMEA-0183 |
| Alarm | Arrival, Anchor, XTE, Interval timer, Userline |
Overview
About this product
The Haiyang HD-880C features an 8 inch color LCD display (SVGA, 800 x 600) with LED backlight and a 52-plus channel GNSS receiver covering GPS, GLONASS, QZSS, and Galileo signals, supported by DGPS and SBAS augmentation. It stores up to 100,000 waypoints, 50,000 track points, and 100 routes, and reads HY-MAP and C-MAP 4D chart data over a Mercator projection display with true motion, N/S/E/W up, course up, and head up modes. It meets IMO Resolution MSC.112(73) and runs on a DC 12V to 36V supply.
Questions
Frequently asked questions
What is the display size and resolution of the Haiyang HD-880C?
The HD-880C has an 8 inch color LCD with LED backlight and SVGA resolution (800 x 600 pixels).
What GNSS receivers does the HD-880C support?
It receives GPS L1 C/A code, GLONASS L10F, QZSS L1 C/A code and Galileo E1B/E1C/L1 over 52-plus channels, with DGPS and SBAS (EGNOS, WAAS, MASA, GAGAN, GLONASS) support.
What chart data works with the Haiyang HD-880C?
The HD-880C uses HY-MAP (built-in or external) or C-MAP 4D chart data.
What is the operating temperature range of the HD-880C?
The display unit is rated for -15°C to +50°C and the antenna unit for -25°C to +70°C.
