AMEC
AMEC A750 Class A AIS Transponder
The futureproof and user-friendly AMEC A750 Key Features: Fully compliant with latest IMO, IEC, and ITU standards Certified for both SOLAS and Inland mode Color 4.3” sunlight readable LCD display Intuitive user-interface and operation Integrated Pilot Plug…
- Brand
- AMEC
- Category
- Marine
- Availability
- Enquire for lead time
Downloads
Technical
Specifications
| Applicable Standards | IEC 61993-2 Ed. 3.0: 2018; IMO Resolution A.694(17); IEC 61108-1 Ed. 2: 2003; IMO Resolution MSC.74(69) Annex 3; IEC 60945 Ed. 4: 2002 incl. Corr. 1 (2008); IMO Resolution MSC.191(79); IEC 61162-1 Ed.5.0: 2016; IMO Resolution MSC.302(87); IEC 61162-2 Ed.1.0: 1998; ITU-R M.1371-5 (Class A): 2014; IEC 61162-450 Ed.2.0: 2018; IEC 62288 Ed.3.0: 2021; IEC 62923-1 Ed. 1.0: 2018; IEC 62923-2 Ed. 1.0: 2018; CESNI Inland AIS test standard Ed. 2021/3.0 |
|---|---|
| VHF Transceiver Frequency | AIS 1: 161.975 MHz; AIS 2: 162.025 MHz |
| VHF Channel Bandwidth | 25 KHz |
| VHF Modulation | GMSK / FM |
| VHF Data Rate | 9,600 bps |
| AIS Channel 1 | CH 87B (161.975 MHz) |
| AIS Channel 2 | CH 88B (162.025 MHz) |
| Tx Power Output | 1/12.5 Watt (30/41 dBm ± 1.5 dB) |
| Rx Sensitivity | < -107 dBm @ 20% PER |
| DSC Receiver Frequency | 156.525 MHz |
| DSC Receiver Modulation | FSK |
| DSC Receiver Channel Bandwidth | 25 K |
| DSC Receiver Sensitivity | < -112 dBm @ 1% BER |
| DSC Receiver Spurious Response Rejection | ≧ 70 dB for signal @ -104 dBm; BER ≦ 1 % |
| DSC Receiver Blocking | ≧ 84 dB for signal @ -104 dBm; BER ≦ 1 % |
| GNSS Receiver Type (internal) | 72-channels; GPS, GLONASS, BeiDou, Galileo; SBAS: WASS, EGNOS, MSAS, GAGAN |
| GNSS Accuracy | Position: 2.5m CEP; SBAS: 2.0m CEP |
| GNSS Sensitivity | Default mode: GPS & GLONASS; Tracking & Navigation: -164 dBm; Reacquisition: -160 dBm |
| Supply Voltage | 12 V / 24 V DC |
| Supply Voltage Range | 9.6 V DC ~ 31.2 V DC |
| Peak Current Draw | 3.60 A @ 12 V DC; 1.72 A @ 24 V DC |
| LCD Screen Size | 4.3” color TFT |
| LCD Pixel Number (Resolution) | 480 x 272 |
| Dimmer Control | Change brightness manually or automatically |
| Nominal Viewing Distance | 52 cm |
| Keypad | 11 Keypads with Back-light: Function, ESC, Voyage/SRM, MENU, Screen Brightness, DISP, Enter, Arrow Keys |
| USB (Front Panel) | Mini type B USB interface |
| SD Card Slot | MicroSD type, support for exFAT and FAT32 |
| Pilot Plug | Std. Sex 206486-2 |
| Power Connector | Round type, 3 pins |
| GPS Antenna Connector | TNC (Female) |
| VHF Antenna Connector | SO-239 (Female) |
| Ethernet | Compliance with IEEE 802.3u, 10Base-T/100Base-TX |
| Data Connector | 37-pins, connect to Junction Box via extension cable |
| Sensor Interfaces 1 to 3 | IEC 61162-1 or -2 (baud rate support: 38400 default, 9600, 4800) |
| Pilot / Auxiliary Interface | IEC 61162-2 |
| External Display Interface | IEC 61162-2 |
| Long Range Interface | IEC 61162-2 |
| DGNSS Correction Input | RTCM-SC-104 |
| Alarm Relay | Normally closed |
| NMEA2000 | IEC61162-3 |
| Alarm Output | Relay contact |
| Blue Sign Switch | Connect to external Blue sign switch |
| Operating Conditions | IEC 60945 “protected” category |
| Operating Temperature | -25 °C ~ 55 °C |
| Operating Humidity | 93 % RH at 40 °C |
| Waterproof | IP54 |
| Width | 262 mm (10.32 inch) |
| Height | 135 mm (5.32 inch) |
| Depth (include connectors) | 197 mm (7.76 inch) |
| Weight (main unit) | 1.25 kg |
| Pilot Plug Cable Length (optional) | 2 m |
| Pilot Plug Connector Type (optional) | Std. Sex 206486-2 |
Overview
About this product
The A750 is the next generation Class A / Inland AIS Transponder that represents AMEC’s innovation milestone in AIS technology. With a redesigned architecture from the ground-up and inside-out, A750 sets a new standard for reliability, performance, and value. The transponder incorporates a modern graphical user interface (GUI) with a sunlight readable 4.3-inch color display for intuitive operation. Its weather robust design with IPx6 waterproof makes it the ideal choice for SOLAS vessels, inland ships, work boats, and superyachts. The A750 AIS Class A transponders is fully certified to the latest IEC 61993-2 Ed. 3.0, IEC 61162-1 Ed. 5.0, IEC 62923-1/-2 Ed.1.0, CCNR Inland AIS Ed.3.0, and other related international standards.
New Color Display
The new 4.3” 1,000 nits color LCD display is now larger and brighter for easy viewing. It provides the space to accommodate onscreen software keyboard for intuitive data input.
Modern GUI Designs
The new modern minimalistic User Interface offers a cleaner design for faster information acquisition.
Integrated Pilot Plug Interface
A pilot plug connector located in the waterproof hatch on the front panel ensures easy access. Optional pilot plug is also available through junction box connection.
Certified for SOLAS and Inland
Ready for operation both at high sea and in rivers.
Complete Connection Interface
NMEA 0183, NMEA 2000, Ethernet and USB enable easy integration with other bridge devices.
Questions
Frequently asked questions
Is the AMEC A750 a SOLAS-compliant Class A transponder?
Yes. The A750 is fully compliant with IEC 61993-2 Ed. 3.0:2018, IMO Resolution A.694(17) and ITU-R M.1371-5 (Class A):2014, and it is certified for both SOLAS and Inland mode operation.
What GNSS constellations does the A750 support?
It uses an internal 72-channel GNSS receiver covering GPS, GLONASS, BeiDou and Galileo, plus SBAS augmentation (WAAS, EGNOS, MSAS, GAGAN), giving a position accuracy of 2.5 m CEP (2.0 m CEP with SBAS).
What power supply does the A750 need?
It runs on 12 V or 24 V DC, accepting a supply range of 9.6 V to 31.2 V DC, with a peak current draw of 3.60 A at 12 V DC or 1.72 A at 24 V DC.
What kind of display does the A750 have?
A 4.3 inch color TFT sunlight-readable LCD at 480 x 272 resolution, with a nominal viewing distance of 52 cm and manual or automatic brightness control.
