Icom
IC-M94D — fixed mount radios from Icom.
Technical
| Frequency range (Tx) | 156.025–157.425 MHz |
|---|---|
| Frequency range (Rx) | 156.050–163.275 MHz |
| Frequency range (Rx CH70) | 156.525 MHz |
| Frequency range (RX AIS) | 162.025 MHz |
| Usable channel groups | INT, USA, CAN, WX channels |
| Type of emission | 16K0G3E (FM), 16K0G2B (DSC), 16K0GXW (GMSK) |
| Current drain TX (6 W/1 W output) | 1500 mA/700 mA (approx.) |
| Current drain RX (Inter SP/Exter SP Max. audio) | 700 mA/350 mA (approx.) |
| Operating temperature range | –20°C to +60°C; –4˚F to +140˚F |
| Antenna impedance | 50 Ω |
| Dimensions (W×H×D) | 60.9 × 145.8 × 43.8 mm; 2.4 × 5.7 × 1.7 in |
| Weight (approximately) | 357 g; 12.6 oz (With BP-306, antenna, MB-133) |
| Output power (Hi/Low) | 6 W/1 W |
| Max. frequency deviation | ±5 kHz |
| Frequency stability | ±10 ppm |
| Spurious emissions | –68 dBc typical |
| Sensitivity (at 12 dB SINAD) | 0.25 μV typical |
| DSC receiver sensitivity (at 1% BER) | –3 dBμ emf typical |
| AIS receiver sensitivity (at 20% PER) | –107 dBm |
| Squelch sensitivity (Threshold) | 0.25 μV typical |
| Adjacent channel selectivity | 70 dB typical |
| DSC receiver adjacent channel selectivity (at 1% BER) | 73 dBμ emf |
| AIS receiver adjacent channel selectivity (at 20% PER) | 50 dB typical |
| Spurious response | 70 dB typical |
| DSC receiver spurious response (at 1% BER) | 73 dBμ emf |
| AIS receiver spurious response (at 20% PER) | 50 dB typical |
| Intermodulation | 70 dB typical |
| DSC receiver intermodulation (at 1% BER) | 68 dBμ emf |
| AIS receiver intermodulation (at 20% PER) | 50 dB typical |
| Hum and noise | 40 dB |
| Audio output power internal speaker (at 10% distortion) | 1500 mW typical (8 Ω load) |
| Audio output power external speaker (at 10% distortion) | 350 mW typical (8 Ω load) |
| Water | IPX7 (Waterproof protection) |
Overview
IC-M94D — fixed mount radios from Icom.
