Icom
IC-F5023
VHF Analog Transceivers General Features 128 memory channels Front mounted speaker 6 programmable buttons MIL grade rugged construction Most popular signalings built-in MDC 1200 compatible Multiple 2-Tone, Multiple 5-Tone Radio kill, stun and revive Lone…
- Brand
- Icom
- Category
- Land Mobile
- Manufacturer
- Icom website ↗
- Availability
- Enquire for lead time
Downloads
Technical
Specifications
| Frequency coverage | 136-174MHz |
|---|---|
| Number of channels | Max. 128 Ch/ 8 zones |
| Channel spacing | 12.5/25kHz |
| Type of emission | 16K0F3E, 11K0F3E |
| Current drain - Tx | 5.0A |
| Current drain - Rx Max. audio | 0.7A |
| Current drain - Stand-by | 250mA |
| Dimensions (W×H×D) | 150×40×117.5 mm |
| Weight (approx.) | 0.8kg |
| RF output power | 25W |
| Spurious emissions | 70dB typ. |
| Frequency stability | ±2.5ppm |
| Audio harmonic distortion | 3% typical, 40% deviation |
| FM Hum and Noise (W) | 46dB typ. |
| FM Hum and Noise (N) | 40dB typ. |
| Sensitivity at 12dB SINAD | 0.25μV typ. |
| Adjacent channel selectivity (W/N) | 75dB/65dB typ. |
| Spurious response rejection | 80dB typ. |
| Intermodulation rejection | 75dB typ. |
| AF output power (4Ω load, 5% distortion) | 4W typ. |
Overview
About this product
The IC-F5023 series is ideal for small-to-mid sized systems for public safety, large industry to light commercial users. The IC-F5023 series offers multiple signaling, advanced scanning, improved external channel control capability and wide frequency coverage packed in a compact body. This rugged mobile easily exceeds your expectations with its reliable performance and communication quality.
Questions
Frequently asked questions
What frequency range does the Icom IC-F5023 cover?
The IC-F5023 covers the 136-174MHz VHF band, with a channel capacity of up to 128 channels across 8 zones and 12.5/25kHz channel spacing.
How much transmit power does the IC-F5023 put out?
The IC-F5023 delivers 25W of RF output power.
What are the dimensions and weight of the IC-F5023?
The IC-F5023 measures 150 x 40 x 117.5 mm and weighs approximately 0.8kg.
